1. Imported high-power LED cold light source, LED secondary optical design
2. Imported gold wire, super high intensity and illumination uniformity
3. Red light, blue light available
4. Five treatment panels, and treatment panel could be adjusted to different
shapes according to different treatment parts
5. Treatment panel is easy and convenient to change
6. Two treatment modes available: time or dose
7. 8 inch color touch screen, simple operation
8. Adjustable 10 levels of irradiation intensity, pulse mode
9. Non-invasive, non-damaged
10. No special care after treatment, make up normally"
Applicable departments:
Orthopedics, Pain, Rehabilitation, Surgery, Burns, dermatology, Skin Beauty, etc
Technical requirements and parameters:
| Working voltage |
AC100 240V 50H/60H±2% |
| rated power |
300VA |
| Overall dimensions |
800mm*500mm*1500mm(length*width*height) |
| Package dimensions |
42cm*64cm*130cm(length*width*height) |
| Weight |
N.W.:40KGS(treatment head:4KGS) G.W.:61KGS |
| Applicable range |
Suitable for the treatment of inflammatory acne, eliminating inflammation |
| Display method |
8 inch colorful touch LCD screen |
| irradiation method |
continuous irradiation, pulse irradiation |
| Effective irradiation area |
930cm² |
| Working distance |
5～8cm |
| Output wavelength range |
Red light 633nm±10nm |
| Blue light 417nm±10nm |
| Effective irradiation |
Pure red light≥80mW/cm²， pure blue light≥100mW/cm² |
| Treatment head shell temperature |
≤60% |
| Timing function |
can be set arbitrarily within the range of 0min to 99min, with an error of ± 2% |
| Mobile bracket |
lifting distance 86～126cm±1cm |
| Support rotation angle |
200° |
| Treatment head type |
Red light ,blue light |
